According to theSD-WAN 7.6 Core Administratorstudy guide and theFortinet Document Library, FortiOS maintains strict referential integrity for SD-WAN objects. An SD-WAN member interface cannot be deleted or removed from the configuration if it is still being "used" or referenced by other features.

Reference Locking: In the FortiOS GUI, the "Delete" button for an SD-WAN member is typically grayed out or an error message appears if the interface is part of an active service or monitoring tool.

Performance SLA Dependency: Performance SLAs (health checks) monitor specific member interfaces. If an interface is a participant in an SLA, it is considered "active" by the system. Therefore, a critical first step in the decommissioning process is toremove the member from all Performance SLA definitions. Once the health check is no longer polling that interface, one major reference lock is released.

Other Dependencies: While firewall policies and SD-WAN rules (service rules) also create references, the question specifies the member is "no longer used to steer traffic," implying it may have already been removed from steering rules. However, Performance SLAs often remain active in the background, making their removal the essential next step to permit the deletion of the member itself.

Why other options are incorrect:

Option A: Moving a member between zones doesn't help you delete it; it just changes its logical grouping. It still remains an active SD-WAN member.

Option B: Disabling the physical interface does not remove the configuration references within the SD-WAN engine. The FortiGate will simply report the member as "Down," but it will still exist in the configuration as a member.

Option D: In modern SD-WAN deployments, static routes usually point to theSD-WAN Zone(like virtual-wan-link) rather than individual physical interfaces. Therefore, you don't typically need to delete the static route to remove a single member from the zone.

"If a flow is identified as belonging to a defined application category (such as social media), FortiGate will match it to the corresponding service rule (rule 2) and route it through the specified interface, such as port2. However, if the application is not recognized during the session setup, the system defaults to load balancing the traffic using the available tunnels according to the policy for unclassified traffic, ensuring continuous connectivity while waiting for application classification."

This guarantees both performance and resilience.

According to theSD-WAN 7.6 Core Administratorstudy guide and theFortinet Document Library, the interaction between SD-WAN rules and SLA targets is governed by specific selection and measurement logic:

Usage by Strategy (Option B): SLA targets are fundamentally used by theLowest Cost (SLA)strategy to determine which links are currently healthy enough to be considered for traffic steering. While other strategies likeBest Qualityuse a "Measured SLA" to monitor metrics, they do not typically use the "Required SLA Target" to disqualify links unless specifically configured in a hybrid mode. In most curriculum contexts, the "Required SLA Target" field is specifically associated with the Lowest Cost and Maximize Bandwidth strategies.

SLA Compliance Checking (Option D): SD-WAN rules utilize SLA targets as a "pass/fail" gatekeeper. The engine checks if thepreferred membersmeet the defined SLA requirements (latency, jitter, or packet loss thresholds). If a preferred member fails the SLA, the rule will move to the next member in the priority list that does meet the SLA.

Single SLA Binding (Option E): When configuring an SD-WAN rule, the GUI and CLI allow you to selectmultiple SLA targets, but they must all belong to thesame Performance SLAprofile. You cannot mix and match targets from different health checks (e.g., Target 1 from "Google_HC" and Target 2 from "Amazon_HC") within a single SD-WAN rule.

Why other options are incorrect:

Option A: This is incorrect because a single SD-WAN rule can only be associated with one specific Performance SLA profile at a time; therefore, you cannot select targets fromdifferentSLAs.

Option C: This is incorrect because member metrics (latency, jitter, packet loss) are measured by thePerformance SLAprobes regardless of whether an SD-WAN rule is currently using that SLA target for steering decisions. Measurement is a function of the health-check, not the rule matching process.
